Hoe bucket HD XHD
M0 to M7+ Carriers from 800kg to 90t
The earthworking bucket is the classic excavator tool. Available in several widths, for your excavation or earthworking jobs. Bucket with deep profile, bare to avoid rubbing in trenches, with a double bottom as standard, to ensure a long working life.
The bucket comprises a welded boxed weld beam equipped, in the standard (HD) version with a full double bottom and lateral protections bosses. We can equip your buckets to order with most spare parts brands on the market.
The XHD versions can be customised as required, with the addition of flats, shields, shoes, etc.
Available in systems
Technical data
-
Module 0 Carriers from 800kg to 2t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 00 R00-200 200 9 17 33 R00-250 250 11 21 41 R00-300 300 14 22 47 R00-350 350 17 24 55 R00-400 400 20 27 63 R00-450 450 23 29 70 R00-500 500 26 31 78 R00-600 600 32 36 94 Series 01 R01-200 200 11 18 38 R01-250 250 14 22 47 R01-300 300 18 23 56 R01-350 350 21 26 64 R01-400 400 25 29 74 R01-450 450 29 31 83 R01-500 500 33 34 93 Series 02 R02-200 200 15 25 52 R02-250 250 19 30 64 R02-300 300 24 34 77 R02-350 350 29 38 90 R02-400 400 34 42 103 R02-450 450 40 46 118 R02-500 500 45 51 132 R02-550 550 50 54 144 R02-600 600 55 59 158 R02-650 650 60 62 170 R02-700 700 66 66 185 R02-800 800 76 75 212 -
Module 1 Carriers from 2t to 3.5t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 12 R12-260 260 30 44 98 R12-300 300 36 48 113 R12-350 350 44 52 131 R12-400 400 52 59 153 R12-450 450 61 64 174 R12-500 500 70 68 194 R12-550 550 78 74 214 R12-600 600 86 79 234 R12-650 650 95 84 255 R12-700 700 103 88 273 R12-750 750 112 94 296 R12-800 800 120 106 322 Series 13 R13-260 260 42 50 126 R13-300 300 44 53 132 R13-350 350 54 58 155 R13-400 400 65 63 180 R13-450 450 75 68 203 R13-500 500 86 74 229 R13-550 550 96 79 252 R13-650 650 118 87 299 R13-700 700 128 95 325 R13-750 750 139 99 349 R13-800 800 150 111 381 -
Module 2 Carriers from 3.5t to 5.5t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 22 R22-300 300 58 71 175 R22-350 350 69 76 200 R22-400 400 82 84 232 R22-450 450 95 89 260 R22-500 500 108 97 291 R22-550 550 125 103 328 R22-600 600 136 109 354 R22-650 650 153 115 390 R22-700 700 166 123 422 R22-750 750 180 129 453 R22-800 800 184 144 475 R22-850 850 201 151 513 R22-900 900 210 158 536 Series 23 R23-300 300 68 75 197 R23-350 350 84 80 231 R23-400 400 100 88 268 R23-450 450 116 94 303 R23-500 500 126 102 329 R23-550 550 148 108 374 R23-600 600 164 114 409 R23-650 650 181 108 434 R23-700 700 197 128 483 R23-750 750 214 134 519 R23-800 800 218 148 540 R23-850 850 233 157 576 R23-900 900 264 163 638 R23-1000 1 000 297 190 725 -
Module 3 Carriers from 5.5t to 7.5t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 31 R31-P2N-300 300 96 113 286 R31-P6N-320 320 90 126 288 R31-P2N-350 350 105 117 306 R31-400 400 115 119 326 R31-450 450 137 128 375 R31-500 500 157 144 427 R31-600 600 198 161 517 R31-700 700 239 178 608 R31-750 750 260 187 655 R31-800 800 280 193 697 R31-900 900 322 220 800 R31-950 950 343 228 845 R31-1000 1 000 364 238 893 Series 32 R32-P2N-300 300 96 120 293 R32-P6N-320 320 90 132 294 R32-P2N-350 350 105 123 312 R32-400 400 115 125 332 R32-450 450 137 134 381 R32-500 500 157 148 431 R32-550 550 177 161 480 R32-600 600 198 168 524 R32-650 650 219 177 571 R32-700 700 239 185 615 R32-750 750 260 196 664 R32-800 800 280 203 707 R32-850 850 301 212 754 R32-900 900 322 228 808 R32-950 950 343 235 852 R32-1000 1 000 364 246 901 -
Module 4 Carriers from 7.5t to 10t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 40 R-4CP6E-350 350 87 162 319 R40-P2E-400 400 144 165 424 R40-P1E-450 450 147 169 434 R40-P1E-500 500 170 167 473 R40-P1E-600 600 211 212 592 R40-P1E-700 700 259 230 696 R40-P1E-800 800 307 248 801 R40-P1E-900 900 356 272 913 R40-P1E-1000 1 000 404 290 1 017 Series 41 R-4CP6E-350 350 87 162 319 R41-P2E-400 400 173 186 497 R41-P1E-450 450 185 195 528 R41-P1E-500 500 213 202 585 R41-P1E-600 600 264 237 712 R41-P1E-700 700 325 253 838 R41-P1E-800 800 386 278 973 R41-P1E-900 900 448 304 1 110 R41-P1E-1000 1 000 510 331 1 249 Series 42 R-4CP6E-350 350 87 162 319 R42-P2E-400 400 173 193 504 R42-P1E-450 450 185 207 540 R42-P1E-500 500 213 219 602 R42-P1E-600 600 264 250 725 R42-P1E-700 700 325 271 856 R42-P1E-800 800 386 302 997 R42-P1E-900 900 448 324 1 130 R42-P1E-1000 1 000 510 345 1 263 R42-P1E-1100 1 100 573 376 1 407 -
Module 5 Carriers from 10t to 15t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 52 R-5CP2E-400 400 245 315 756 R-5CP2E-450 450 255 320 779 R-5CP1E-520 520 297 345 880 R-5CP1E-600 600 377 399 1 078 R52-P1E-700 700 369 376 1 040 R52-P1E-800 800 441 404 1 198 R52-P1E-900 900 514 435 1 360 R52-P1E-1000 1 000 588 481 1 539 R52-P1E-1100 1 100 662 519 1 711 R52-P1E-1200 1 200 736 519 1 844 Series 53 R-5CP2E-400 400 245 327 768 R-5CP2E-450 450 255 322 781 R-5CP1E-520 520 297 362 897 R-5CP1E-600 600 377 412 1 091 R53-P1E-700 700 418 424 1 176 R53-P1E-800 800 500 464 1 364 R53-P1E-900 900 584 494 1 545 R53-P1E-1000 1 000 668 525 1 727 R53-P1E-1100 1 100 754 564 1 921 R53-P1E-1200 1 200 839 595 2 105 -
Module 6 Carriers from 15t to 24t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 61 R-6CP2E-400 400 433 478 1 257 R-6CP2E-500 500 386 477 1 172 R-6CP1E-620 620 492 550 1 436 R-6CP1E-700 700 518 520 1 452 R-6CP1E-800 800 596 579 1 652 R-6CP1E-900 900 697 619 1 874 R61-P1E-1000 1 000 719 738 2 032 R61-P1E-1100 1 100 812 683 2 145 R61-P1E-1200 1 200 905 727 2 356 R61-P1E-1300 1 300 999 764 2 562 Series 62 R-6CP2E-400 400 433 491 1 270 R-6CP2E-500 500 386 507 1 202 R-6CP1E-620 620 492 555 1 441 R-6CP1E-700 700 518 563 1 495 R-6CP1E-800 800 596 588 1 661 R-6CP1E-900 900 697 663 1 918 R62-P1E-1000 1 000 837 701 2 208 R62-P1E-1200 1 200 1 058 815 2 719 R62-P1E-1300 1 300 1 168 860 2 963 R62-P1E-1400 1 400 1 279 904 3 206 Series 63 R-6CP2E-400 400 433 508 1 287 R-6CP2E-500 500 386 504 1 199 R-6CP1E-620 620 492 569 1 455 R-6CP1E-700 700 518 581 1 513 R-6CP1E-800 800 596 603 1 676 R-6CP1E-900 900 697 685 1 940 R63-P1E-1000 1 000 837 752 2 259 R63-P1E-1200 1 200 1 125 847 2 872 R63-P1E-1400 1 400 1 362 954 3 406 R63-P1E-1500 1 500 1 481 999 3 665 R63-P1E-1600 1 600 1 599 1 055 3 933 -
Module 7 Carriers from 24t to 45t
Series Reference Width Capacity Bucket weight Total weight* (mm) ISO (l) (kg) (kg) Series 71 R71-P1E-850 850 800 929 2 369 R71-P1E-1400 1 400 1 370 1 317 3 783 R71-P1E-1500 1 500 1 500 1 375 4 075 R71-P1E-1600 1 600 1 620 1 438 4 354 R71-P1E-1700 1 700 1 740 1 520 4 652 Series 72 R72-P1E-850 850 900 1 023 2 643 R72-P1E-1000 1 000 1 140 1 229 3 281 R72-P1E-1300 1 300 1 480 1 451 4 115 R72-P1E-1500 1 500 1 780 1 596 4 800 R72-P1E-1600 1 600 1 930 1 668 5 142 R72-P1E-1700 1 700 2 090 1 740 5 502 Series 73 R73-P1E-1100 1 100 1 450 1 811 4 640 R73-P1E-1300 1 300 1 710 2 140 5 483 R73-P1E-1400 1 400 1 900 2 305 5 905 R73-P1E-1500 1 500 2 100 2 470 6 327 R73-P1E-1600 1 600 2 300 2 634 6 749 R73-P1E-1800 1 800 2 700 2 964 7 592
Total weight = (ISO capacity in L x Density 1.8) + Bucket weight in kg
This is an example of realization, all our tools are customizable, find out more.
