Skeleton grid bucket
M0 to M4 Carriers from 800kg to 10.5t
Skeleton grid backhoes are designed for the sorting, sifting and filtering of materials.
For example, you can remove cobblestones and separate them from the sand in which they were laid.
The bucket mesh is obtained by the spacing of the vertical webs and the gap between the horizontal bars.
An alternative to this construction is to make a grid: a thick base is cut out to the dimensions of the mesh.
For this type of product, we propose one or two standard meshes, but tailored to meet your need is preferable.
The buckets are of conventional construction. They are particularly robust and have options and our expertise to order.
The skeleton grid backhoes have a minimum pitch of 50mm, unlike the grid backhoes which are not limited.
Available in systems
Technical data
This is an example of realization, all our tools are customizable, find out more.
| Module | Profile | Min. Width | Max. Width | Coupler size |
|---|---|---|---|---|
| (mm) | (mm) | |||
| Module 0 Carriers from 800kg to 2t |
P1N | 500 | 1000 | M0S |
| Module 1 Carriers from 2t to 3.5t |
P1N | 500 | 1000 | M1S |
| Module 2 Carriers from 3.5t to 5.5t |
P1N | 500 | 1000 | M2S |
| Module 3 Carriers from 5.5t to 7.5t |
P1N | 500 | 1200 | M3S |
| Module 4 Carriers from 7.5t to 10t |
P1E | 500 | 1200 | M4S |
